Ball mill

Ball mills is a key equipment for grinding materials sales@sinoftm.com

Ball Mill

  • 0.65-615t/h

    Production capacity

  • ≤25mm

    Feeding size

Material handling effect

  • gold ore

  • copper ore

  • limestone

  • manganese

  • chrome

Chat Online Now Send Your Inquiry
Brief in ball mill

Ball mills are widely used in cement, silicate products, new building materials, refractory materials, fertilizers, black and non-ferrous metal dressings, and glass ceramics. Dry or wet grinding of various ores and other materials.

  • Energy-saving: fully hydraulic operation, easy to use and automate.
  • High grinding efficiency:High quality of the lining and grinding body .
  • Good operating conditions:stable operation, less dust.

Customer case

Product Commitments
  • 1. We guarantee that our products are all up to standards set for mining machinery.
  • 2. We will deliver products timely by contract.
  • 3. We will supply you with installation drawings, specifications and operation manual.
  • 4. We offer lifetime warranty and components for products.

Service Guarantee

Professional mining machinery manufacturer with over 40 years of experience.

Chat Online Now

Ball Mill Price

The favorable price to provide you with quality services

Specific price is determined by many factors, such as ball mill types, models, etc.

As the advanced manufacturer and exporter in china, our ball mills are factory-direct sold, which offer you premium quality and better service.

Click here to get a quote

About FTM

Technical Data

  • Ball Mill
  • Ceramic Ball Mill
  • Rod Mill
Model Feeding
size
(mm)		 Capacity
(t/h)
Ф900×1800 <20 0.65-2
Ф900×3000 <20 1.1-3.5
Ф1200×2400 <25 1.5-4.8
Ф1200×3000 <25 1.6-5
Ф1200×4500 <25 1.6-5.8
Ф1500×3000 <25 2-5
Ф1500×4500 <25 3-6
Ф1500×5700 <25 3.5-6
Ф1830×3000 <25 4-10
Ф1830×4500 <25 4.5-12
Ф1830×6400 <25 6.5-15
Ф1830×7000 <25 7.5-17
Ф2100×3000 <25 6.5-36
Ф2100×4500 <25 8-43
Ф2100×7000 <25 12-48
Ф2200×4500 <25 9-45
Ф2200×6500 <25 14-26
Ф2200×7000 <25 15-28
Ф2200×7500 <25 15-30
Ф2400×3000 <25 7-50
Ф2400×4500 <25 8.5-60
Ф2700×4000 <25 22-80
Ф2700×4500 <25 26-90
Ф3200×4500 <25 As per process
conditions
Ф3600×4500 <25 As per process
conditions
Ф3600×6000 <25 As per process
conditions
Ф3600×8500 <25 45.8-256
Ф4000×5000 <25 45-208
Ф4000×6000 <25 65-248
Ф4000×6700 <25 75-252
Ф4500×6400 <25 84-306
Ф5030×6400 <25 98-386
Ф5030×8300 <25 118-500
Ф5500×8500 <25 148-615
Model Feeding capacity
（t/time）		 Shell rotation speed
（r/min）		 Liner material
600×700 0.05 50 Chinaware,silicon,rubber or metal（the related motor power varied as per the different liner materials and grinding materials）
800×600 0.075 42
900×1200 0.2 38.5
1300×1500 0.5 33
1500×1800 1.2 28.5
1800×2000 1.5 24
2600×2800 5 16.5
3000×3800 10 14.5
3200×4600 15 13.5
Model
Shell Specifications （mm）
 Feeding size
(mm)		 Processing capacity
(t/h)
Diameter Length
MBS0918 900 1800 ≤25 0.62-3.2
MBS0924 900 2400 ≤25 0.81-4.3
MBS1224 1200 2400 ≤25 1.1-4.9
MBS1530 1500 3000 ≤25 2.4-7.5
MBS1830 1830 3000 ≤25 4.8-11.6
MBS2130 2100 3000 ≤25 14-35
MBS2136 2100 3600 ≤25 19-43
MBS2430 2400 3000 ≤50 25-65
MBS2736 2700 3600 ≤50 32-86
MBS2740 2700 4000 ≤50 32-92
MBS3245 3200 4500 ≤50 64-180
